Shenzhen Tendzone Intelligent Technology Co., Ltd. is one of the most reliable manufacturers and suppliers of 6' coaxial ceiling speaker in China. Please feel free to wholesale high quality 6' coaxial ceiling speaker made in China here from our factory. We also accept customized orders.
Overview
The ACS series of new generation ceiling speakers adopts coaxial drive technology, uses a full-band speaker with a two-way drive structure, and has a built-in crossover, which makes ACS suitable for conference sound reinforcement, background music system and other places, with good sound performance.
This product adopts a high-strength metal stamping cavity, which is stamped and formed in one time. The entire sound-supporting cavity ensures that the speaker is in a stable state even at high energy output, maintains a large dynamic output, makes its sound more perfect, and reduces the noise interference in the ceiling. It solves the problems that the ceiling installation structure and speakers usually have, including noise, resonance, and poor sound quality in the ceiling.
The ABS material front baffle adopts a matte matte black design, which is beautiful and dustproof, with an adsorption mesh cover and a frameless design, which is more coordinated with the ceiling and shows high-end.
Product Size
Hot Tags: 6' coaxial ceiling speaker, China 6' coaxial ceiling speaker manufacturers, suppliers, factory, Dante audio processor, 4K60 4 4 4 Network AV Encoder Decoder, 4 5 Vailink Network Powered Column Speaker, network audio distribution, Audio DSP, MIDIS AV Over IP Server
SPECIFICATIONS
|
General Performance |
|
|
Name |
6-inch coaxial ceiling speaker |
|
Frequency response (-10dB) |
95 Hz~ 19k Hz |
|
Rated Power |
60W |
|
Long term maximum power |
120W |
|
Peak Power |
240W |
|
Sensitivity (1W/1m) |
89 ± 2 dB |
|
Maximum sound pressure level |
107 ±2dB continuous 113 ±2dB peak |
|
Coverage angle ( HxV ) |
100 °x 100 ° |
|
Impedance |
8Ω ±2 0 % |
|
Woofer |
1 x 6.5 " |
|
Tweeter |
1" |
|
Box material |
ABS+ Ferrite Cavity |
|
Grille Color |
White |
|
Connection Terminals |
4pin Phoenix terminal With L OOP function |
|
Dimensions (diameter x depth) |
264 x 162mm |
|
Opening size |
Φ 240mm |
|
Weight |
3.2 kg |
