16×16 Digital Audio Processor - AEC · AFC · AGC · Auto-Mixing · Web-Based Control

Product Overview

The ARES Q1616 is a professional digital audio processor built on the powerful ADSP-21569 floating-point DSP core. It provides a complete suite of audio processing functions - AEC (acoustic echo cancellation), AFC (adaptive feedback cancellation), ANS (noise suppression), AGC (automatic gain control), auto-mixing, ducker, limiter and full parametric EQ - covering the sound-reinforcement needs of most audio systems.

The 16 × 16 configuration offers 16 channels of balanced microphone/line inputs with +48 V phantom power and 16 channels of balanced line outputs, at a 24-bit / 48 kHz sampling rate. A B/S-architecture software platform allows PC or mobile devices to log in remotely through a browser to adjust parameters and download manuals, while the embedded system design keeps the processor free from virus interference for outstanding operating stability.

The ARES Q1616 is widely used in conference rooms, churches, star-rated hotels, auditoriums, conference centers, multi-function halls, digital courtrooms and other venues that demand reliable, high-quality sound reinforcement.

Key Features







Audio I/O & Sound Quality

• 16 channels of balanced microphone/line inputs with 48 V phantom power soft switch.

  16 channels of balanced line outputs.

  24-bit / 48 kHz sampling rate for outstanding audio quality.

  Optimized preamp gain with 0 dB / 10 dB / 20 dB / 30 dB / 40 dB settings, accommodating both MIC and LINE levels.

  USB 2.0 audio interface supporting recording and playback via USB flash drive (MP3 / WAV, FAT32).





Acoustic Processing

• Adaptive Feedback Cancellation (AFC) - high-speed floating-point algorithms provide feedback suppression for each microphone channel, with 16 suppression points and manual / dynamic / fixed processing modes, effectively eliminating "howling".
• Shared adaptive Acoustic Echo Cancellation (AEC) - processed independently on every input channel with a 512 ms tail, swiftly eliminating echoes in video conferences; built-in ANS removes up to 18 dB of noise.
• Automatic Gain Control (AGC) - keeps system output volume stable regardless of how far the presenter is from the microphone.
• Intelligent Ducker - microphone signals automatically duck background music, highlighting the vocals.
• Instant-response limiter to perfectly protect downstream equipment.
• Threshold-type and gain-sharing automatic mixing (AM) for easy management of multi-microphone combinations and clear sound reinforcement.

Application Scenarios

• Conference rooms and boardrooms - echo-free far-end audio for video conferencing.
• Digital courtrooms - intelligible, stable speech reinforcement for proceedings.
• Conference centers and multi-function halls - flexible zone routing and EQ tuning.
• Auditoriums and lecture halls - automatic feedback suppression with multiple microphones.
• Churches and houses of worship - natural vocals over background music via ducker.
• Star-rated hotels - background music paging with priority ducking announcements.

System Solution

Microphones and program sources feed the 16 balanced inputs, where the ARES Q1616 applies preamplification, AEC / AFC / ANS / AGC, auto-mixing and equalization. The processed signals are routed to power amplifiers and speakers through the 16 balanced outputs, recorded to or played back from a USB flash drive, and delivered to video conferencing terminals with far-end echo fully cancelled. Engineers can tune every parameter remotely from a browser, while third-party control systems integrate via TCP/IP or RS-232.
