Product Overview
The air environment detector is suitable for the detection and display of indoor air quality. It can measure PM2.5 and ambient temperature and humidity in the air (two interfaces are reserved for formaldehyde or CO2), segment code screen (black background with white characters and backlight), ZigBee wireless communication method compatible with WIFI module (TYWE3S), 86 box wall-mounted, it reliably connects to the gateway through ZigBee and uploads environmental data information to the gateway.
Hot Tags: embedded air environment detector, China embedded air environment detector manufacturers, suppliers, factory, Vailink Desktop Embedded Gooseneck Condenser Microphone, Vailink 2CH Analog Output Adapter, IP speaker, 6 Vailink Network Coaxial Ceiling Speaker, network speaker, Vailink 2CH Analog Input Adapter
Specifications
|
General Parameters |
|
|
Wireless type |
ZigBee |
|
Transmitting frequency |
2.4 GHz |
|
Transmit power |
≤1 9 dBm |
|
Communication distance |
100 meters (open space) |
|
Operating voltage |
External AC220V |
|
Temperature range |
-20 ~ 70℃ |
|
Temperature accuracy |
±0.5℃ |
|
Humidity range |
0 ~ 99%RH |
|
Humidity accuracy |
±5%RH |
|
PM1.0/PM2.5 /PM10 range |
0 ~ 999 ug/m3 |
|
PM1.0/PM2.5 /PM10 accuracy |
0~100ug/m³：±15ug/m³ ＞100ug/m³：±15% |
|
Air quality level |
PM2.5 (ug/m³) 0~75: Excellent PM2.5 (ug/m³) 76~115: Good PM2.5 (ug/m³) >115: Polluted |
|
Screen |
Segment screen-black background, white text, backlight |
|
Network configuration button |
support |
|
Formaldehyde |
compatible |
|
CO2 |
compatible |
|
"+-" button |
compatible |
|
Dimensions |
86*86*28 mm |
