HD Recording and Broadcasting Server HRS500-8
1080P 8-Channel Lecture-Capture & Live-Streaming Appliance - 6× SDI + HDMI + VGA, Web Director, RTMP/RTSP/RTP
Product Overview
The HRS500-8 is a dedicated HD recording and broadcasting appliance designed to capture, compose, encode, record, and stream visual content from a single 1U rack-mount chassis. It accepts up to eight 1080P video sources through 6× 3G-SDI, 1× HDMI and 1× VGA interfaces, together with two audio channels, and provides multiple composition layouts for lecture capture, live streaming and on-demand playback.
Built on an embedded industrial hardware platform, the HRS500-8 combines the performance of dedicated hardware with the flexibility of browser-based control. It records to a 2 TB internal drive in standard MP4/FLV formats, supports H.264 video and AAC audio encoding, and delivers content through HTTP/RTMP and RTSP/RTP. With fanless cooling, four RS-232 COM ports and a Gigabit LAN port, the unit is ideal for education, remote medicine, surveillance visualisation, government and defence applications.
- 1080P capture - 6× 3G-SDI + 1× HDMI + 1× VGA inputs accepting 1080P/60, 1080I, 720P and other resolutions with automatic detection.
- Audio integration - 2× RCA LINE IN inputs and 1× RCA LINE OUT output, plus HDMI embedded audio output.
- Flexible composition - single view, conversation view, triple view, multi-view, PiP and user-defined layouts.
- Multiple outputs - 2× HDMI local output plus 1× VGA output, with RTMP/RTSP/RTP network streaming for remote viewers.
- Reliable storage - built-in 2 TB drive (expandable to 4 TB) for local MP4/FLV recording, with FTP/IPSAN expansion.
- Web-based director - remote switching, monitoring, camera control, preset recall and device management through a browser.
- Multi-protocol streaming - H.264-FLV over HTTP/RTMP and H.264-RTP over RTSP/RTP for broad compatibility.
- Silent operation - fanless 1U 19" rack-mount design, auto-ranging AC 100–240 V, max 150 W.
Key Features
Multi-Format 1080P Video Input
- Six 3G-SDI inputs plus one HDMI and one VGA input support 1080P/60, 1080I, 720P and other common formats.
- Sources are indexed and mapped to physical connectors for easy identification during direction.
- Automatic resolution detection and manual configuration handle non-standard signals.
Flexible Video Composition
- Camera signals, PC screens and other sources can be combined freely into preset or custom layouts.
- Five recording modes: single view, conversation view, triple view, multi-view and PiP/PoP.
- Resource mode records 1× HDMI/VGA + 6× SDI, or 1× HDMI/VGA + 4× RTSP + 2× SDI; movie mode records up to 7 mixed-screen signals.
Output, Streaming & Recording
- 2× HDMI outputs and 1× VGA output automatically detect display resolution and refresh rate.
- H.264 video encoding and AAC audio encoding; HTTP/RTMP and RTSP/RTP streaming protocols.
- Selectable stream quality to match campus LAN or public-network bandwidth.
- Records standard MP4/FLV files compatible with mainstream players and learning-management systems.
- Supports up to 15 concurrent live / VOD users after recording.
Built-In Director & Control
- Web-based director supports remote switching, PTZ camera control, preset configuration and system management.
- 4× RS-232 COM ports with SDK support for TCP/UDP/232 integration with control panels.
- USB mouse and keyboard can be connected directly for local control.
- Scrolling subtitles and logo overlay are configurable in position, colour and size.
Application Scenarios
It can be widely applied in education, telemedicine, surveillance and video telephony, government departments, and other fields.
Education
routine recording classrooms, smart classrooms, lecture halls, and dual-teacher remote classrooms.
Remote medicine
surgical observation, remote consultation, and medical training broadcast.
Government & enterprise
meeting minutes, training sessions, and command-centre visual archiving.
System Solution
In a typical deployment, SDI cameras, an HDMI camera or lecturer PC and a VGA source feed the HRS500-8 through the eight physical inputs. Additional IP streams can be pulled in as RTSP/RTP. The built-in web director selects layouts, switches sources, and overlays subtitles or logos. The finished program is delivered through two HDMI outputs and one VGA output to classroom displays, streamed to remote learners over HTTP/RTMP or RTSP/RTP, and stored locally as MP4/FLV files. Operators can manage the system locally with a USB mouse/keyboard or over the LAN.
About Tendzone
Established in 2010, Tendzone is a global leader in providing advanced audio-visual (AV) solutions and manufacturing high-quality AV products. We specialize in a wide range of cutting-edge technologies, including audio processors, microphones, speakers, power amplifiers, AV over IP systems, digital conference systems, and MIDIS Distributed Multimedia Transmission Control Systems. Our solutions are trusted across industries such as conference rooms, command centers, education, multi-functional halls, and stadiums.
Our Service
Our dedicated customer support team offers reliable technical support, quick response times, and preventive maintenance service.
Pre-Sales
We assess your unique requirements, provide tailored consultations and demonstrations, and design a customized AV system to ensure the perfect solution.
In-Sales
We deliver transparent proposals, manage the full project implementation, and provide initial training to ensure a smooth and successful setup.
After-Sales
We offer prompt technical support, customized maintenance plans, continuous software upgrades, and actively use your feedback to drive ongoing service improvement.
Tendzone, established in 2010, is a global leader in providing advanced audio-visual (AV) solutions and manufacturing high-quality AV products. We specialize in a wide range of cutting-edge technologies, including audio processors, microphones, speakers, power amplifiers, AV over IP systems, digital conference systems, and MIDIS Distributed Multimedia Transmission Control Systems. Our solutions are trusted across industries such as conference rooms, command centers, education, multi-functional halls, and stadiums.
Our address
Building 1A, Building 16, Shenzhen International Innovation Valley, Dashi 1st Road, Nanshan District, Shenzhen
Phone Number
Mobile/Wechat/WhatsApp : (+86) 13302998794
travis.tu@tendzone.com
Hot Tags: hd recording and broadcasting server hrs500-8, China hd recording and broadcasting server hrs500-8 manufacturers, suppliers, factory
Technical Specifications
|
Video Input Interfaces |
6× 3G-SDI video inputs |
|
Audio Input Interfaces |
2× LINE IN (RCA) audio inputs |
|
Video Encoding |
H.264 - Baseline / Main / High Profile |
|
Audio Encoding |
AAC |
|
Supported Resolutions |
1080P / 1080I / 720P / Full D1 / VGA / CIF |
|
Max Frame Rate |
60 fps for HD video |
|
Bitrate Range |
16 Kbps – 40 Mbps |
|
Video Output |
2× HDMI video outputs (embedded audio) |
|
Audio Output |
1× LINE OUT (RCA) |
|
File Format |
MP4 / FLV |
|
Storage |
2 TB hard disk as standard; up to 4 TB optional |
|
Recording Layouts |
Resource mode: 1× HDMI/VGA + 6× SDI |
|
IP Streaming Protocol |
H.264-FLV over HTTP / RTMP |
|
Physical & Power |
1U standard 19" rack mount |
|
Operating Conditions |
Operating temperature: 0 °C – 50 °C |
