Shenzhen Tendzone Intelligent Technology Co., Ltd. is one of the most reliable manufacturers and suppliers of 8x8 digital audio processor in China. Please feel free to wholesale high quality 8x8 digital audio processor made in China here from our factory. We also accept customized orders.
Features
- High-Resolution digital audio processors : Utilizes 24-bit/48kHz sampling rate for outstanding audio quality.
- Optimized Gain Control: Offers multi-level gain adjustment options (0dB, 10dB, 20dB, 30dB, 40dB) suitable for both MIC and LINE levels.
- USB 2.0 Audio Interface: Supports USB flash drives for recording and playback.
- Adaptive Feedback Cancellation (AFC): Uses high-speed floating-point digital algorithms to provide feedback suppression for each microphone, effectively reducing feedback "howling" in amplification systems.
- Automatic Gain Control (AGC): Ensures stable output volume from the sound system, regardless of the speaker's varying distance from the microphone.
- Intelligent Ducker (DUCKER): Easily suppresses background music signals through the microphone, allowing the vocal to be more pronounced.
- Instantaneous Limiter Response: Provides perfect protection for downstream equipment.
- Selectable Automatic Mixing Modes: Offers threshold-type and gain-sharing automatic mixing (AM) for easily managing multiple microphone outputs and delivering clear sound reinforcement.
- Shared Adaptive Echo Cancellation (AEC): Provides processing for each input channel to quickly eliminate echo during video conferences.
- Parametric Equalizer: Features multiple filter types, including PEQ, High-Shelf, NOTCH, Low-Shelf, Low Pass (LP), and High Pass (HP), ensuring flexible application in various scenarios.
- WEB Operating Interface: Available in both English and Chinese, featuring an intuitive graphical user interface for easy human-computer interaction.
- Ethernet Control Interface: Supports 1000M/100M Ethernet connectivity for direct computer connection, network interlinking, and cross-router control.
- Open Third-Party Control Protocol: Allows management and control of the audio processor via network or RS-232 interfaces.
Hot Tags: 8x8 digital audio processor, China 8x8 digital audio processor manufacturers, suppliers, factory, Analog Ceiling Array Microphone, Audio Signal processing, web based audio processors, network speaker, IP microphoe, DANTE DSP
SPECIFICATIONS
|
General Performance |
|||
|
Frequency Response(A/D/A) |
20Hz～20kHz (±0.5dB) |
||
|
Sampling Rate |
48kHz,24bit |
||
|
Dynamic Range(A/D/A) |
>106dB,A-weighted(20Hz-20kHz@0dB Gain) |
||
|
THD |
≤0.005%@1kHz,+4dBu |
||
|
Latency (A/D/A) |
5.8 mS, inputs routed to outputs |
||
|
Noise Floor (A-weighted) |
≤-90dBu |
||
|
Crosstalk |
≤-105dB@+20dBu,1kHz |
||
|
S/N Ratio |
>110dB,A-weighted(20Hz-20kHz@0dB Gain) |
||
|
Channel Isolation |
≤-105dB@+20dBu,1kHz |
||
|
Preset Numbers |
50 |
||
|
Audio Input/Output |
|||
|
model |
ARES Q0808 |
ARES Q1616 |
|
|
Connector |
3.81 mm terminal blocks |
||
|
Number of Analog Channels |
8in8out |
16in16out |
|
|
Phantom Power |
DC 48±6V,10mA |
||
|
Input Impedance |
2KΩ balance |
||
|
Output Impedance |
200Ω balance |
||
|
Maximum Input Level |
20dBu |
||
|
Maximum Output Level |
20dBu |
||
|
Max Input Gain |
40dB |
||
|
Front Panel |
|||
|
Indicator Light |
Power/RUN/LINK |
||
|
Rear Panel |
|||
|
USB |
Interface type is USB-A and the data transfer protocol is USB2.0. Support recording and playback, can play MP3/WAV format audio files, support FAT32 format U disk, recording file format WAV |
||
|
RS232 |
3pin 3.81Phoenix terminal |
||
|
LAN(TCP/IP Network Port) |
Ethernet 10/100/1000MB RJ45 |
||
|
Electrical and Physical Parameters |
|||
|
Power Supply |
AC100-240V±10%,50/60Hz |
||
|
Power Consumption |
24W |
||
|
Operating Temperature |
0℃-45℃ |
||
|
Relative Humidity |
30%～70％R.H. |
||
|
Dimensions |
484mm*260mm*44mm |
||
|
Package size |
570mmx410mmx135mm |
||
|
Net Weight |
2.7Kg |
2.8Kg |
3.1Kg |
|
Shipping Weight |
3.2KG |
3.34KG |
3.6Kg |
